Rated Voltage: 250VAC
Rated Current: 16A
Operating frequency: DC ~ 60Hz
Insulation Resistance:
line to ground: ≥500MΩ/500VDC
Leakage Current ( 250VAC/50Hz ): ≤3mA
Operating Temperature Range: -20℃ ~ +70℃
Insertion Loss in dB: ≥100dB（1MHz ~ 100MHZ）

Compact unit, easy to install, custom design acceptable; Suppressing the electromagnetic interference by power cord conduction; Good anti-saturation and harmonic suppression function.
